33kv Circuit Breaker

DAYA 33kv Circuit Breaker Details

Maximize your productivity with reduced downtimes with ABB’s flagship product family of VD4 circuit breakers for primary and secondary protection, with a global installed base of over 2 million units and higher performance than the market standard. Protect your assets with an optimum interface, utilizing the market’s widest portfolio of circuit breakers, covering global standards and ratings fitting your specific needs.Medium voltage circuit breakers with mechanical actuator (spring mechanism) for primary distribution up to 46 kV, 4000 A, 63 kA.

DAYA 33kv Circuit Breaker  Condition:

Key benefits

The most versatile and powerful solution among medium voltage vacuum circuit breakers

Ideal for all applications (eg, capacitor bank switching, marine, GOST)

More than 2 million VD4 medium voltage vacuum circuit breaker installed worldwide

Cassettes and module systems available for OEMs and panel builders to create their own solutions

Fully interchangeable — both for overall dimension and electrical diagram — with ABB VD4 medium voltage gas circuit breaker

Only one common plug-and-play actuator (EL type) from 12 kV to 36 kV with a wide range of accessories, safety locks and interlocks, and with same family feeling of ABB low voltage series EMAX

Key features

Vacuum interrupters embedded in poles for protection against humidity, shocks and dust

Modular spring-operated mechanical actuator ensuring easy operation even without auxiliary supply

30,000 mechanical operations on most ratings

Rated at up to 46 kV, 4000 A, 63 kA.

DAYA 33kv Circuit Breaker  Processing characteristics

Cabinet part: all right-angled parts that operators may come into contact with are all reversed at R angles to prevent scratching and hurting people; the improved busbar frame is more convenient to install busbars and has a more beautiful appearance; the ventilation grid installed on the top cover has anti- Drip function; the top cover is an open structure, which is convenient for users to place horizontal busbars on site;

 2. Drawer part: the drawer adopts double-folding positioning groove rivet riveting process, and all parts are molded at one time, so that the drawer is 100% interchangeable. At the same time, the double-folding and rivet technology solves the defects of sheet burr and self-tapping screw tip injury;

3. Connectors: The first-time plug-in for the incoming and outgoing lines of the drawer can be directly used in conjunction with the function board and the metal channel, and the secondary connector is convenient to connect and the wiring is beautiful;

4. Vertical channel: half functional board or iron rectangular channel can be selected, and can be easily interchanged.

DAYA 33kv Circuit Breaker  FAQ

1.Q: Are you a manufacturer or trader?

A:We are all, Main business of the company low-voltage switchgear, power distribution cabinet, explosion-proof cabinet design, production and system programming.

2.Q: Whether to support OEM/ODM?Can you design the equipment according to our size?

A: Of course, we can customize any product according to customer requirements, and we can provide design solutions and solutions.

3.Q: Why should I buy from you instead of someone else?

A: First of all, we can provide all customers with very professional support consisting of IT consultants and service teams.Secondly, our main engineers have more than 20 years of experience in power distribution equipment development.

4.Q:What about the delivery time?

A:Generally, our delivery time is around 7-15 days about. While, it depends on the requirement of customers and the

quantity of products.

5.Q:What about the shipment?

A:We can arrange shipment by DHL, FedEx, UPS,etc.of course, customers can also use their own freight forwarders.

6.Q:How about the terms of payment?

A:Supported T/T、Paypal、Apple Pay、Google Pay、Western Union,etc. Of course we can discuss on this.
