0.6/1 kV Multi-core unarmoured with copper conductor cables

DAYA electrical is a large-scale 0.6/1 kV Multi-core unarmoured with copper conductor cables manufacturer and supplier in China. We have been specialized in High voltage equipment for many years. Our products have a good price advantage and cover most of the South America, Middle East, Africa, Southeast Asia markets. We look forward to becoming your long-term partner in China.Used as bare overhead transmission conductor and as primary and secondary distribution conductor and messenger support. Multi-core offers optimal strength for line design. Variable steel core stranding enables desired strength to be achieved without sacrificing ampacity

APPLICATION

Multi-core LSZH cable with steel wire armour (SWA). Power and auxiliary fixed wiring cables for use in power networks, underground, outdoor and indoor applications and for use in cable ducting. For installation where fire, smoke emission and toxic fumes create a potential threat to life and equipmentACSR Conductor Standards

B-230 Aluminum wire, 1350-H19 for Electrical Purposes

B-231 Aluminum conductors, concentric lay stranded

B-232 Aluminum conductors, concentric lay stranded, coated steel reinforced (ACSR)

B-341 Aluminum coated steel core wire for aluminum conductors, steel reinforced (ACSR/AZ)

B-498 Zinc coated steel core wire for aluminum conductors, steel reinforced (ACSR)

B-500 Metallic coat

CHARACTERISTICS

Voltage Rating

Uo/U 0.6/1kV

Temperature Rating

Fixed intallation: -20°C to +90°C

Minimum Bending Radius

1.5mm2 to 16mm2 - Fixed: 6 x overall diameter 25mm2 and above - Fixed: 8 x overall diameter

DAYA 0.6/1 kV Multi-core unarmoured with copper conductor cables Details

DAYA 0.6/1 kV Multi-core unarmoured with copper conductor cables Working conditions

Specifications:

Size (AWG or KCM): 636.0

Stranding (AL/STL): 26/7

Diameter Inches: Aluminum: 0.1564

Diameter Inches: Steel: 0.1216

Diameter Inches: Steel Core: 0.3648

Diameter Inches: Cable OD: 0.990

Weight lb/1000FT: Aluminum: 499.

Weight lb/1000FT: Steel: 276.2

Weight lb/1000FT: Total: 874.1

Content %: Aluminum: 68.53

Content %: Steel: 31.47

Rate Breaking Strength (lbs.): 25,200

OHMS/1000ft: DC at 20ºC: 0.0267

OHMS/1000ft: AC at 75ºC: 0.033

Ampacity: 789 Amps

Packing:

--100m/Coil with Shrinking Film Wrap, 6 Coils per outer carton.

--100m/Spool, spool can be Paper, Plastic, or ABS, then 3-4 spools per carton,

--200m or 250m per Drum, two drums per carton,

--305m/Wooden Drum, one drum per outer carton or pallet loading,

--500m/Wooden Drum, one drum per outer carton or pallet loading,

--1000m or 3000m wooden drum, then pallet loading.

*We can also offer customized OEM packing according to clients' request.

Delivery:

Port: Tianjin, or other ports as per your requirements.

Sea freight: FOB/C&F/CIF quotation are all available.

*For some countries such as Africa countries, middle east countries, our sea freight quotation is much cheaper than clients get from local shipping agency.

DAYA 0.6/1 kV Multi-core unarmoured with copper conductor cables Parameter (Specification)

Nominal cross sectional area		ELECTRICALDATA						DIMENSIONSANDWEIGHTS		Cable Code
		Max. Conductor Resistance		Continuous Current Ratings				Approx. overall diameter	Approx. overall weight
		DC at 20 °C	AC at 70 °C	Laid in ground	Laid in ducts		Laid in free air
mm²		Ω / km	Ω / km	A	A		A	mm	kg / km
Two Core Cables
1.5	rm	12.1000	14.4777	27	19		21	9.9 145 C208PA10200CB01IMR
2.5	rm	7.4100	8.8661	36	24		28	10.8 185 C210PA10200CB01IMR
4	rm	4.6100	5.5159	47	32		38	12.7 260 C212PA10200CB01IMR
6	rm	3.0800	3.6853	58	40		48	13.8 330 C213PA10200CB01IMR
10	rm	1.8300	2.1898	76	53		65	15.0 420 C314PA10200CB01IMR
16	rm	1.1500	1.3763	98	70		86	17.0 580 C315PA10200CB01IMR
25	rm	0.7270	0.8703	127	92		116	20.1 855 C316PA10200CB01IMR
35	rm	0.5240	0.6276	152	111		142	22.2 1100 C317PA10200CB01IMR
Three Core Cables
1.5	rm	12.1000	14.4777	23		15	18	10.4 170 C208PA10300CB04IMR
2.5	rm	7.4100	8.8661			20	23	11.4 220 C210PA10300CB04IMR
4	rm	4.6100	5.5159	38		26	32	13.4 315 C212PA10300CB04IMR
6	rm	3.0800	3.6853			33	40	14.7 400 C213PA10300CB04IMR
10	rm	1.8300	2.1898	63		43	55	16.4 500 C314PA10300CB04IMR
16	rm	1.1500	1.3763			57	72	18.6 720 C315PA10300CB04IMR
25	rm	0.7270	0.8703	105		75	98	21.9 1020 C316PA10300CB04IMR
35	sm	0.5240	0.6276			85	107	21.2 1310 C417PA10300CB04IMR
50	sm	0.3870	0.4639	139		103	131	24.6 1715 C418PA10300CB04IMR
70	sm	0.2680	0.3220			128	166	27.7 2355 C419PA10300CB04IMR
95	sm	0.1930	0.2328	204		156	204	32.1 3205 C445PA10300CB04IMR
120	sm	0.1530	0.1856			178	235	34.0 3940 C446PA10300CB04IMF
				Four Core Ca		bles
1.5	rm	12.1000	14.4777			15	18	11.3 205 C208PA10400CB08IMR
2.5	rm	7.4100	8.8661	29		20	23	12.3 265 C210PA10400CB08IMR
4	rm	4.6100	5.5159			26	32	14.6 385 C212PA10400CB08IMR
6	rm	3.0800	3.6853	48		33	40	16.0 500 C213PA10400CB08IMR
10	rm	1.8300	2.1898			43	55	17.9 670 C314PA10400CB08IMR
16	rm	1.1500	1.3763	81		57	72	20.3 920 C315PA10400CB08IMR
25	rm	0.7270	0.8703			75	98	24.1 1295 C316PA10400CB08IMR
35	sm	0.5240	0.6276	117		85	107	24.5 1665 C417PA10400CB08IMR
50	sm	0.3870	0.4639			103	131	28.7 2220 C418PA10400CB08IMR
70	sm	0.2680	0.3220	170		128	166	32.3 3055 C419PA10400CB08IMR
95	sm	0.1930	0.2328			156	204	36.2 4200 C445PA10400CB08IMR
120	sm	0.1530	0.1856	231		178	235	39.6 5185 C446PA10400CB08IMF
150	sm	0.1240	0.1514			203	270	44.3 6390 C447PA10400CB08IMF
185	sm	0.0991	0.1224	292		232	311	49.1 7905 C448PA10400CB08IMF
240	sm	0.0754	0.0952			272	370	55.6 10280 C449PA10400CB08IMS
300	sm	0.0601	0.0780	381		310	426	61.7 12840 C450PA10400CB08IMS
400	sm	0.0470	0.0638			357	495	70.3 16455 C451PA10400CB08IMS
500	sm	0.0366	0.0531	484		405	568	77.8 21170 C452PA10400CB08IMS
Four Core Cables with Reduced Neutral
25 rm	16 rm 0.7270 / 1.1500		0.8703 / 1.3763	105	75		98	23.1 1215 C334PA10400CB08IMR
35sm	16 rm 0.5240 / 1.1500		0.6276 / 1.3763	117	85		107	24.5 1480 C435PA10400CB08IMR
50sm	25 rm 0.3870 / 0.7270		0.4639 / 0.8703	139	103		131	28.7 2005 C436PA10400CB08IMR
70sm	35sm 0.2680 / 0.5240		0.3220 / 0.6276	170	128		166	32.3 2745 C437PA10400CB08IMR
95sm	50sm 0.1930 / 0.3870		0.2328 / 0.4639	204	156		204	36.2 3700 C438PA10400CB08IMR
120sm	70sm 0.1530 / 0.2680		0.1856 / 0.3220	231	178		235	39.6 4665 C439PA10400CB08IMF
150sm	70sm 0.1240 / 0.2680		0.1514 / 0.3220	259	203		270	44.3 5605 C440PA10400CB08IMF
185sm	95sm 0.0991 / 0.1930		0.1224 / 0.2328	292	232		311	49.1 7035 C441PA10400CB08IMF
240sm	120sm 0.0754 / 0.1530		0.0952 / 0.1856	338	272		370	55.6 9045 C442PA10400CB08IMS
300sm	150sm 0.0601 / 0.1240		0.0780 / 0.1514	381	310		426	61.7 11290 C443PA10400CB08IMS
400sm	185sm 0.0470 / 0.0991		0.0638 / 0.1224	431	357		495	70.3 14375 C444PA10400CB08IMS
500sm	240sm 0.0366 / 0.0754		0.0531 / 0.0952	484	405		568	77.8 18415 C466PA10400CB08IMS

DAYA 0.6/1 kV Multi-core unarmoured with copper conductor cables Service

Pre-sales

We provide technical support and complete power distribution solutions tailored to your needs. If the design drawings you provide are deemed unfeasible, we will optimize the plan and adjust it with the dimensions of the cabinet, the location of the equipment, and so on. We will also optimize the configuration of the products to make them meet your requirements.

After-Sales

If any problem occurs, we will first provide support by phone or email. We will perform a remote debug if necessary. Furthermore, our products come with a troubleshooting manual for reference when trying to find the fault and solve issues by yourself. Most problems can be solved by the above-mentioned methods. We will check in every year or so to acquire detailed information about your equipment to get a better understanding of the inner workings.

Our customer service promise

1. We will quickly solve the problem after receiving the issue report or repair request.

2. We then explain the cause of failure in detail and any fees will be charged according to market pricing.

3. If we take any parts back for inspecting, we will apply fragile notice stickers on them or write their serial number down to maintain the safety of the parts.

4. If your complaint is deemed valid, we will refund repair fees to you on-site.

DAYA Sf6 Circuit Breaker FAQ

1.Q: Are you a manufacturer or trader?

A:We are all, Main business of the company low-voltage switchgear, power distribution cabinet, explosion-proof cabinet design, production and system programming.

2.Q: Whether to support OEM/ODM?Can you design the equipment according to our size?

A: Of course, we can customize any product according to customer requirements, and we can provide design solutions and solutions.

3.Q: Why should I buy from you instead of someone else?

A: First of all, we can provide all customers with very professional support consisting of IT consultants and service teams.Secondly, our main engineers have more than 20 years of experience in power distribution equipment development.

4.Q:What about the delivery time?

A:Generally, our delivery time is around 7-15 days about. While, it depends on the requirement of customers and the

quantity of products.

5.Q:What about the shipment?

A:We can arrange shipment by DHL, FedEx, UPS,etc.of course, customers can also use their own freight forwarders.

6.Q:How about the terms of payment?

A:Supported T/T、Paypal、Apple Pay、Google Pay、Western Union,etc. Of course we can discuss on this.

Hot Tags: 0.6/1 kV Multi-core unarmoured with copper conductor cables, China, Factory, Manufacturers, Suppliers, Price
